WRECKER INT 35

35 TON HEAVY WRECKER

Overview

INT-35 Thirty-five-ton integrated wheel and boom lift available in tandem or tri-axel configurations. INT-35 is an everyday heavy wrecker ideal for everything from tractor trailer switches to recovery jobs. This unit will spend little time in your yard as it’ll always be on the road grabbing the good paying calls. It has been designed from the ground up with the operator in mind.

From the gas-shock tool box doors to the standard complete wireless controls this wrecker will be the envy of every heavy driver. Keeping you rolling is our priority, so we’ve gone with all steel hydraulic lines and we’ve used only the best in cylinders, winches and steel. We’ve designed the INT-35 to work in any environment and it will fill the gap in your fleet.

As with all many tow trucks, customisation is the order of the day and we’ll build your wrecker the way you want it. Don’t hesitate to inquire; standard and customized wreckers are surprisingly inexpensive.

Standard Features Include:

4114 mm (162”) Cab to centre of tandem steel body
Two 20-ton (44,000 lbs) winch
Frame fork holders
Frame fork racks
Chain racks
4 sets of frame forks
Chrome door handle
Driver and passenger-side manual controls
Safety chains

Options Available:

Wireless Remote Control
20-ton (44,000 lbs) winches
609 mm (24″), 762 mm (30″), 914 mm (36″), 1219 mm (48″), 1828 mm (72″) tunnel box
Custom length tunnel box
Extra frame forks
Wheel lift receivers for single/double tires
Full recovery tool package
Custom storage system
Aluminium / Composite body
European body style
Gravel guard undercoating finish
Front push bumper
XP, X-shape side puller
Chrome handrails
A-arm style side winches
In-cab controls
European style low under lift
Full size LED light bar
LED – working lights, strobe lights, lights inside toolbox
Custom painting
Installation services and extended warranty
Tow operators’ education & training

Specifications:

Underlift Specifications / * = Euro Option

Retracted capacity on forks  15.8 ton (35,000 lbs) / * 14 ton (31,000 lbs)
Retracted distance to the forks  1514 mm (60”) / * 1701 mm (67”)
Extended capacity on forks  7.2 ton (16,000 lbs) / * 5.4 ton (12,000 lbs)
Extended distance to the forks  2936 mm (116”) / * 3657 mm (144”)
Negative tilt angle  -6°
Tow Rating  36.2 ton (80,000 lbs)

Boom Specifications

Retracted capacity (at 32°)  35 ton (77,100 lbs)
Extended capacity (at 32°)  17,5 ton (38,500 lbs)
Maximum Lift angle  32°
Maximum Hook Height  5913 mm (233”)
Reach Past Tailboard  3373 mm (133”)

Vehicle Recommendations

Front axle(s) weight (min)  6 ton (13,200 lbs)
Rear axle(s) weight (min)  2 x 9 ton (20,000 lbs)
Recommended GVW  24 ton (53,200 lbs)
Recommended Tyre size R22,5
Clear CA  4114 mm (162”)

Winch Specifications

Quantity  2 pcs
Pulling force (on 1st layer)  20 ton (44,000 lbs)
Winch type  Planetary
Cable length  19 mm x 60 m (3/4″ x 200′)
